2BE3 Series Liquid Ring Vacuum Pumps and Compressors

Low-speed, heavy-load design; with a cavitation protection device; stainless steel shaft sleeve enhances shaft service life. Internal inspection of the pump and replacement of the exhaust valve plate, shaft sleeve, and shaft seal can be performed through inspection ports without disassembly.

Home > Vacuum Pump Series > 2BE3 Series Liquid Ring Vacuum Pumps and Compressors

Product Features

Ultimate Vacuum

Vacuum pump ultimate vacuum 2.7kPa (A), high-efficiency range 3.3~20kPa (A)

Maximum Discharge Pressure

Compressor max. discharge pressure 0.15MPa (G), with isothermal compression

Strong Adaptability

Capable of suctioning high-humidity gases (including saturated steam), gases containing solid particles, as well as toxic, corrosive, flammable, explosive, and hazardous gases

Multi-Purpose Pump

By adding an intermediate partition, both ends can operate under different suction pressures, and the suction pressure difference can reach 33kPa

Cavitation Protection

Equipped with a cavitation protection device

Stable and Reliable

Low-speed and heavy-load, high reliability

Long Shaft Life

Stainless steel shaft sleeves extend the service life of the shaft

Flexible Installation

Reserve side suction and exhaust ports, and suction and exhaust can be set at the top or side respectively

Convenient Maintenance

No need for disassembly, the internal condition of the pump can be inspected through the inspection hole, and the exhaust valve plate, shaft sleeve and shaft seal can be replaced
