Horizontal Axially Split Multistage Pumps
(VMB03 Series)
The VMB03 series pumps are horizontal, side suction and discharge, multistage, near-centerline-mounted, axially split, between-bearing heavy-duty petrochemical process pumps, classified as API 610 BB3 type.
Product Features
Independent R&D building upon international design concepts and manufacturing experience
01
Excellent hydraulics utilizing CFD and ANSYS software
02
Internationally advanced, representing a new generation of high-efficiency and energy-saving product
03
Advanced structure, stable operation, and high reliability
04
Inlet/outlet nozzles located on the lower casing, allowing pump system assembly/disassembly without removing pipelines or motor
05
Double volute casing design with back-to-back impeller arrangement for self-balanced axial forces and extended bearing life
06
Impellers mounted to the shaft via shrink fitting for enhanced stability and reliability
07
Rolling, hydrodynamic or forced-lubrication bearings are available based on power and speed
08
Product Introduction
Performance Range
Standard
Performance Range
Flow Rate (Q)
50~2000 m³/h
Head (H)
140~1500 m
Rotational Speed (n)
980, 1480, 2980 rpm
Design Pressure (P)
11.0, 15.0 MPa
Operating Temperature (T)
-80℃ to +180℃
Standard
Standard
API 610 12th Edition Centrifugal Pumps for Petroleum, Petrochemical, and Natural Gas Industries
Applications
-
Petroleum Processing, Production, and Transportation
-
Coal Chemical Processes
-
Petrochemical and Chemical Processes
-
Seawater Desalination
-
Crude Oil Transportation
-
Water Supply
-
Oilfield Water Injection
-
Lean/Rich Liquid Pumps in Ammonia Synthesis Plants
-
Methanol Lean Pump Transportation
-
Boiler Feedwater
-
High-Pressure Hydraulic Energy Recovery Turbines
-
General Industry
