OH1 Petrochemical Process Pumps
(VMH02Z Series)
The VMH02Z series pumps are single-stage overhung petrochemical process pumps featuring end suction, top discharge, radially split casing, foot-mounted support, and a spiral volute pressure chamber, classified as API 610 OH1 type.
Product Features
Stable and reliable structural design
01
Broad hydraulic coverage
02
Internationally advanced in design and performance
03
New generation of high-efficiency and energy-saving product
04
For media with high solid content: Semi-open impeller with wear-resistant plates to effectively reduce maintenance costs
06
For low NPSHa conditions: Inducer added at the impeller inlet to significantly improve cavitation resistance
07
For condensation- or crystallization-prone media: Multiple thermal insulation measures (steam, hot water, or electric) to ensure media fluidity
08
Product Introduction
Performance Range
Standard
Performance Range
Flow Rate (Q)
4~2600 m³/h
Head (H)
12~300 m
Rotational Speed (n)
980, 1480, 2980 rpm
Design Pressure (P)
2.5 MPa
Operating Temperature (T)
-80℃ to +150℃
Standard
Standard
API 610 12th Edition Centrifugal Pumps for Petroleum, Petrochemical, and Natural Gas Industries
Applications
-
Petroleum Processing, Production, and Transportation
-
Coal Chemical Processes
-
Petrochemical and Chemical Processes
-
Natural Gas Industry
-
Metallurgy
-
Power
-
Boiler Circulating Water
-
Water Supply and Treatment
-
Offshore Industry
-
Seawater Desalination
-
Grain Deep Processing
-
General Industry
